X28HC64JIZ-12 IC EEPROM 64KBIT PARALLEL 32PLCC Renesas Electronics America Inc
| Brand Name | Renesas Electronics America Inc |
|---|---|
| Model Number | X28HC64JIZ-12 |
| Minimum Order Quantity | 1 |
| Price | Based on current price |
| Packaging Details | anti-static bag & cardboard box |
| Delivery Time | 3-5 work days |
| Payment Terms | T/T |
| Supply Ability | In stock |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Memory Type | Non-Volatile | Memory Format | EEPROM |
|---|---|---|---|
| Technology | EEPROM | Memory Size | 64Kbit |
| Memory Organization | 8K X 8 | Memory Interface | Parallel |
| Clock Frequency | - | Write Cycle Time - Word, Page | 5ms |
| Access Time | 120 Ns | Voltage - Supply | 4.5V ~ 5.5V |
| Operating Temperature | -40°C ~ 85°C (TA) | Mounting Type | Surface Mount |
| Package / Case | 32-LCC (J-Lead) | Supplier Device Package | 32-PLCC (11.43x13.97) |
You can tick the products you need and communicate with us in the message board.
| Part Number | Description | |
|---|---|---|
| X28HC64JIZ-12 | IC EEPROM 64KBIT PARALLEL 32PLCC | |
| X28HC256JIZ-12T1 | IC EEPROM 256KBIT PAR 32PLCC | |
| X28HC256JIZ-12 | IC EEPROM 256KBIT PAR 32PLCC | |
| X28HC256JIZ-15T1 | IC EEPROM 256KBIT PAR 32PLCC | |
| X28HC256JZ-15T1 | IC EEPROM 256KBIT PAR 32PLCC | |
| X28HC256JIZ-90T1 | IC EEPROM 256KBIT PAR 32PLCC | |
| X28HC256JIZ-15 | IC EEPROM 256KBIT PAR 32PLCC | |
| X28HC256JIZ-90 | IC EEPROM 256KBIT PAR 32PLCC | |
| NM27C256V200 | IC EPROM 256KBIT PARALLEL 32PLCC | |
| NM27C010V150 | IC EPROM 1MBIT PARALLEL 32PLCC | |
| NM27C010VE120 | IC EPROM 1MBIT PARALLEL 32PLCC | |
| NM27C010VE200 | IC EPROM 1MBIT PARALLEL 32PLCC | |
| NM27C040V120 | IC EPROM 4MBIT PARALLEL 32PLCC | |
| NM27C040V200 | IC EPROM 4MBIT PARALLEL 32PLCC | |
| NM27C256V100 | IC EPROM 256KBIT PARALLEL 32PLCC | |
| NM27C256V120 | IC EPROM 256KBIT PARALLEL 32PLCC | |
| NM27C256V150 | IC EPROM 256KBIT PARALLEL 32PLCC | |
| NM27C512V120 | IC EPROM 512KBIT PARALLEL 32PLCC | |
| NM27C512V150 | IC EPROM 512KBIT PARALLEL 32PLCC | |
| NM27C010V120 | IC EPROM 1MBIT PARALLEL 32PLCC | |
| NM27C020V120 | IC EPROM 2MBIT PARALLEL 32PLCC | |
| NM27C020V150 | IC EPROM 2MBIT PARALLEL 32PLCC | |
| NM27C256V90 | IC EPROM 256KBIT PARALLEL 32PLCC | |
| NM27C256VE200 | IC EPROM 256KBIT PARALLEL 32PLCC | |
| NM27C512V90 | IC EPROM 512KBIT PARALLEL 32PLCC | |
| X28HC256J-90 | IC EEPROM 256KBIT PAR 32PLCC | |
| FM27C256V120 | IC EPROM 256KBIT PARALLEL 32PLCC | |
| FM27C256V150 | IC EPROM 256KBIT PARALLEL 32PLCC | |
| X28C512JIZ-12 | IC EEPROM 512KBIT PAR 32PLCC | |
| X28HC64JIZ-90 | IC EEPROM 64KBIT PARALLEL 32PLCC | |
| X28HC64JZ-12 | IC EEPROM 64KBIT PARALLEL 32PLCC | |
| X28HC256JI-90R5697 | IC EEPROM 256KBIT PAR 32PLCC | |
| X28HC256JI-90T1R5699 | IC EEPROM 256KBIT PAR 32PLCC | |
| X28HC256JI-90R5420 | IC EEPROM 256KBIT PAR 32PLCC | |
| X28HC256JI-90R5699 | IC EEPROM 256KBIT PAR 32PLCC |
Product Description
Product Details
DESCRIPTION
The X28HC64 is an 8K x 8 EEPROM, fabricated with Intersil’s proprietary, high performance, floating gate CMOS technology. Like all Intersil programmable nonvolatile memories, the X28HC64 is a 5V only device. It features the JEDEC approved pinout for byte-wide memories, compatible with industry standard RAMs.
FEATURES
• 70ns access time• Simple byte and page write
—Single 5V supply
—No external high voltages or VPP control circuits
—Self-timed
—No erase before write
—No complex programming algorithms
—No overerase problem
• Low power CMOS
—40mA active current max.
—200µA standby current max.
• Fast write cycle times
—64-byte page write operation
—Byte or page write cycle: 2ms typical
—Complete memory rewrite: 0.25 sec. typical
—Effective byte write cycle time: 32µs typical
• Software data protection
• End of write detection
—DATA polling
—Toggle bit
• High reliability
—Endurance: 1 million cycles
—Data retention: 100 years
• JEDEC approved byte-wide pin out
• Pb-free plus anneal available (RoHS compliant)
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Renesas |
| Product Category | Memory ICs |
| Manufacturer | Intersil |
| Product-Category | EEPROM |
| Package-Case | PLCC |
| Memory-Size | 64 kbit |
| Interface-Type | Parallel |
| Organization | 8 k x 8 |
| Data-Retention | 100 Years |
| Supply-Current-Max | 40 mA |
| Operating-Supply-Voltage | 5 V |
| Maximum-Operating-Temperature | + 85 C |
| Series | X28HC64 |
| Access-Time | 120 ns |
| Brand | Intersil |
| Minimum-Operating-Temperature | - 40 C |
| Operating-Supply-Current | 40 mA |
| Supply-Voltage-Max | 5.5 V |
| Supply-Voltage-Min | 4.5 V |
Descriptions
EEPROM 8K X 8 EEPROM,CMOS,HIGH SPEED,PLCC,IND TEMP,120NS,PB FREE
