LT1074CT7#PBF IC REG MULTI CONFG ADJ TO220-7 Analog Devices Inc.
| Brand Name | Analog Devices Inc. |
|---|---|
| Model Number | LT1074CT7#PBF |
| Minimum Order Quantity | 1 |
| Price | Based on current price |
| Packaging Details | anti-static bag & cardboard box |
| Delivery Time | 3-5 work days |
| Payment Terms | T/T |
| Supply Ability | In stock |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Function | Step-Up, Step-Down, Step-Up/Step-Down | Output Configuration | Positive Or Negative |
|---|---|---|---|
| Topology | Buck, Boost, Flyback | Output Type | Adjustable |
| Number Of Outputs | 1 | Voltage - Input (Min) | 8V |
| Voltage - Input (Max) | 45V | Voltage - Output (Min/Fixed) | 2.5V |
| Voltage - Output (Max) | 35V | Current - Output | 5.5A (Switch) |
| Frequency - Switching | 100kHz | Synchronous Rectifier | No |
| Operating Temperature | 0°C ~ 70°C (TA) | Mounting Type | Through Hole |
| Package / Case | TO-220-7 Formed Leads | Supplier Device Package | TO-220-7 |
You can tick the products you need and communicate with us in the message board.
| Part Number | Description | |
|---|---|---|
| LT1074CT7#PBF | IC REG MULTI CONFG ADJ TO220-7 | |
| LT1074HVIT7#PBF | IC REG MULTI CONFG ADJ TO220-7 | |
| LT1074IT7#PBF | IC REG MULTI CONFG ADJ TO220-7 | |
| LT1074HVCT7#PBF | IC REG MULTI CONFG ADJ TO220-7 | |
| LT1076CT7#PBF | IC REG MULT CONFG ADJ 2A TO220-7 | |
| LT1374CT7-5#PBF | IC REG BCK SEPIC 5V 4.5A TO220-7 | |
| LT1371CT7#PBF | IC REG MULT CONFG ADJ 3A TO220-7 | |
| LT1076HVCT7#PBF | IC REG MULT CONFG ADJ 2A TO220-7 | |
| LT1374CT7#PBF | IC REG BUCK SEPIC ADJ 4.5A TO220 | |
| LT1370CT7#PBF | IC REG MULT CONFG ADJ 6A TO220-7 | |
| LT1370HVCT7#PBF | IC REG MULT CONFG ADJ 6A TO220-7 | |
| LT1370IT7#PBF | IC REG MULT CONFG ADJ 6A TO220-7 | |
| LT1370HVIT7#PBF | IC REG MULT CONFG ADJ 6A TO220-7 | |
| LT1076CT7-5#PBF | IC REG MULTI CONFG 5V 2A TO220-7 | |
| LT1374IT7-5#PBF | IC REG BCK SEPIC 5V 4.5A TO220-7 | |
| LT1374IT7#PBF | IC REG BUCK SEPIC ADJ 4.5A TO220 | |
| LT1371HVCT7#PBF | IC REG MULT CONFG ADJ 3A TO220-7 | |
| LT1371IT7#PBF | IC REG MULT CONFG ADJ 3A TO220-7 | |
| LT1371HVIT7#PBF | IC REG MULT CONFG ADJ 3A TO220-7 | |
| LT1076HVCT7-5#PBF | IC REG MULTI CONFG 5V 2A TO220-7 | |
| LT1076HVCT7-5 | IC REG MULTI CONFG 5V 2A TO220-7 |
Product Description
Product Details
DESCRIPTION
The LT®1074 is a 5A (LT1076 is rated at 2A) monolithic bipolar switching regulator which requires only a few external parts for normal operation. The power switch, all oscillator and control circuitry, and all current limit components, are included on the chip. The topology is a classic positive “buck” configuration but several design innovations allow this device to be used as a positive-to-negative converter, a negative boost converter, and as a flyback converter. The switch output is specified to swing 40V below ground, allowing the LT1074 to drive a tapped inductor in the buck mode with output currents up to 10A.
FEATURES
■ 5A Onboard Switch (LT1074)■ 100kHz Switching Frequency
■ Greatly Improved Dynamic Behavior
■ Available in Low Cost 5 and 7-Lead Packages
■ Only 8.5mA Quiescent Current
■ Programmable Current Limit
■ Operates Up to 60V Input
■ Micropower Shutdown Mode
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Analog Devices / Linear Technology |
| Product Category | DC Switching Regulators |
| Series | - |
| Packaging | Tube |
| Package-Case | TO-220-7 (Formed Leads) |
| Operating-Temperature | 0°C ~ 70°C (TA) |
| Mounting-Type | Through Hole |
| Output-Type | Adjustable |
| Function | Step-Up, Step-Down, Step-Up/Step-Down |
| Supplier-Device-Package | TO-220-7 |
| Number-of-Outputs | 1 Output |
| Topology | Buck, Boost, Flyback |
| Frequency-Switching | 100kHz |
| Current-Output | 5.5A (Switch) |
| Output-Configuration | Positive or Negative |
| Output Voltage | 2.5V |
| Voltage-Output-Max | 35V |
| Synchronous-Rectifier | No |
| Voltage-Input-Min | 8V |
| Voltage-Input-Max | 45V |
Descriptions
Buck, Boost, Flyback Switching Regulator IC Positive or Negative Adjustable 2.5V 1 Output 5.5A (Switch) TO-220-7 (Formed Leads)
LT1074 - Step-Down Switching Regulator
