MIC26400YJL-TR IC REG BUCK ADJUSTABLE 5A 28MLF Microchip Technology



General Description

The Micrel MIC26601 is a constant-frequency, synchronous buck regulator featuring a unique adaptive on-time control architecture. The MIC26601 operates over an input supply range of 4.5V to 28V and provides a regulated output of up to 6A of output current. The output voltage is adjustable down to 0.8V with a guaranteed accuracy of ±1%, and the device operates at a switching frequency of 600kHz.





Features

• Hyper Speed Control™ architecture enables
- High Delta V operation (VIN = 28V and VOUT = 0.8V)
- Small output capacitance
• 4.5V to 28V voltage input
• 6A output current capability, up to 95% efficiency
• Adjustable output from 0.8V to 5.5V
• ±1% feedback accuracy
• Any Capacitor™ stable - zero-to-high ESR
• 600kHz switching frequency
• No external compensation
• Power Good (PG) output
• Foldback current-limit and “hiccup mode” short-circuit protection
• Supports safe startup into a pre-biased load
• –40°C to +125°C junction temperature range
• 28-pin 5mm × 6mm MLF® package





Applications

• Distributed power systems
• Communications/networking infrastructure
• Set-top box, gateways, and routers
• Printers, scanners, graphic cards, and video cards
