MPQ2019GN-AEC1-Z IC REG LIN POS ADJ 300MA 8SOIC Monolithic Power Systems Inc.
| Brand Name | Monolithic Power Systems Inc. |
|---|---|
| Model Number | MPQ2019GN-AEC1-Z |
| Minimum Order Quantity | 1 |
| Price | Based on current price |
| Packaging Details | anti-static bag & cardboard box |
| Delivery Time | 3-5 work days |
| Payment Terms | T/T |
| Supply Ability | In stock |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Output Configuration | Positive | Output Type | Adjustable |
|---|---|---|---|
| Number Of Regulators | 1 | Voltage - Input (Max) | 40V |
| Voltage - Output (Min/Fixed) | 1.2V | Voltage - Output (Max) | 15V |
| Voltage Dropout (Max) | 0.55V @ 300mA | Current - Output | 300mA |
| Current - Quiescent (Iq) | 95 µA | Current - Supply (Max) | - |
| PSRR | 45dB (1kHz) | Control Features | Enable, Power Good |
| Protection Features | Over Temperature, Short Circuit | Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount | Package / Case | 8-SOIC (0.154", 3.90mm Width) Exposed Pad |
| Supplier Device Package | 8-SOIC-EP | ||
| Highlight | PMIC Chip,PMIC IC,Power Management Integrated Circuits |
||
You can tick the products you need and communicate with us in the message board.
| Part Number | Description | |
|---|---|---|
| MPQ2019GN-AEC1-Z | IC REG LIN POS ADJ 300MA 8SOIC | |
| MP2019GN-5-Z | IC REG LINEAR 5V 300MA 8SOIC | |
| MP2019GN-33-Z | IC REG LINEAR 3.3V 150MA 8SO | |
| MP2019GN-Z | IC REG LIN POS ADJ 300MA 8SOIC | |
| MPQ2019GN-Z | IC REG LIN POS ADJ 300MA 8SOIC | |
| MPQ2019GN-33-Z | IC REG LINEAR 3.3V 300MA 8SOIC | |
| MPQ2019GN-5-Z | IC REG LINEAR 5V 300MA 8SOIC | |
| MPQ2019GN-33-AEC1-Z | IC REG LINEAR 3.3V 300MA 8SOIC | |
| MPQ2019GN-5-AEC1-Z | IC REG LINEAR 5V 300MA 8SOIC | |
| MPQ2029GN-Z | IC REG LIN POS ADJ 450MA 8SOIC | |
| MPQ2029GN-AEC1-Z | IC REG LIN POS ADJ 450MA 8SOIC | |
| MP2019GN | IC REG LINEAR POS ADJ 300MA | |
| MP2019GN-33 | IC REG LINEAR 3.3V 150MA | |
| MPQ2019GN | IC REG LINEAR POS ADJ 300MA | |
| MPQ2019GN-33 | IC REG LINEAR 3.3V 300MA | |
| MPQ2019GN-AEC1 | IC REG LINEAR POS ADJ 300MA | |
| MPQ2019GN-33-AEC1 | IC REG LINEAR 3.3V 300MA | |
| MP2019GN-5 | IC REG LINEAR 5V 300MA 8SO | |
| MPQ2019GN-5 | IC REG LINEAR 5V 300MA 8SOIC | |
| MPQ2019GN-5-AEC1 | IC REG LINEAR 5V 300MA 8SOIC | |
| MPQ2029GN | IC REG LIN POS ADJ 450MA 8SOIC | |
| MPQ2029GN-AEC1 | IC REG LIN POS ADJ 450MA 8SOIC |
Product Description
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Monolithic Power Systems Inc. |
| Product Category | Linear Voltage Regulators |
| Mfr | Monolithic Power Systems Inc． |
| Series | Automotive AEC-Q100 |
| Package | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® |
| Product-Status | Active |
| Output-Configuration | Positive |
| Output-Type | Adjustable |
| Number-of-Regulators | 1 |
| Voltage-Input-Max | 40V |
| Voltage-Output-Min-Fixed | 1．2V |
| Voltage-Output-Max | 15V |
| Voltage-Dropout-Max | 0．55V @ 300mA |
| Current-Output | 300mA |
| Current-Quiescent-Iq | 95 µA |
| PSRR | 45dB (1kHz) |
| Control-Features | Enable Power Good |
| Protection-Features | Over Temperature Short Circuit |
| Operating-Temperature | -40°C ~ 125°C (TA) |
| Mounting-Type | Surface Mount |
| Package-Case | 8-SOIC (0．154" 3．90mm Width) Exposed Pad |
| Supplier-Device-Package | 8-SOIC-EP |
| Base-Product-Number | MPQ2019 |
Descriptions
Linear Voltage Regulator IC 1 Output 300mA
