0.13" 4.7V Board Mount Temperature Sensor MPXAZ6115AP 16.68PSIA 8SOP

  • 0.13" 4.7V Board Mount Temperature Sensor MPXAZ6115AP 16.68PSIA 8SOP
Brand Name N✖P USA Inc.
Model Number MPXAZ6115AP
Minimum Order Quantity 1
Price Based on current price
Packaging Details anti-static bag & cardboard box
Delivery Time 3-5 work days
Payment Terms T/T
Supply Ability In stock

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Temperature Compensated Applications Board Mount
Pressure Type Absolute Operating Pressure 2.18PSI ~ 16.68PSI (15kPa ~ 115kPa)
Output Type Analog Voltage Output 0.2 V ~ 4.7 V
Accuracy ±1.5% Voltage - Supply 4.75V ~ 5.25V
Port Size Male - 0.13" (3.17mm) Tube Port Style Barbed
Termination Style Gull Wing Maximum Pressure 58.02PSI (400kPa)
Operating Temperature -40°C ~ 125°C Mounting Type Surface Mount
Package / Case 8-SMD, Gull Wing, Side Port Supplier Device Package 8-SOP
Highlight

0.13" Board Mount Temperature Sensor

,

4.7V Board Mount Temperature Sensor

,

MPXAZ6115AP
Leave a Message
Product Description

MPXAZ6115AP SENSOR 16.68PSIA 0.13" 4.7V 8SOP N✖P USA Inc.

Product Details

Description

The MPXxx6115A series sensor integrates on-chip, bipolar op amp circuitry and thin film resistor networks to provide a high output signal and temperature compensation. The small form factor and high reliability of on-chip integration make the pressure sensor a logical and economical choice for the system designer.


Features

• Resistant to high humidity and common automotive media
• Improved accuracy at high temperature
• Available in small and super small outline packages
• 1.5% maximum error over 0 °C to 85 °C
• Ideally suited for microprocessor or microcontroller-based systems
• Temperature compensated from -40 °C to +125 °C
• Durable Thermoplastic (PPS) Surface Mount Package


Application

• Industrial controls
• Engine control/manifold absolute pressure (MAP)
• Weather station and weather reporting device barometers

Specifications

Attribute Attribute Value
Manufacturer Freescale / N✖P
Product Category Pressure Transducers
Series MPXAZ6115A
Packaging Tray
Unit-Weight 0.063207 oz
Mounting-Style SMD/SMT
Termination-Style PCB
Package-Case 8-SMD Module
Operating-Temperature -40°C ~ 125°C
Output-Type Analog Voltage
Features Temperature Compensated
Voltage-Supply 4.75 V ~ 5.25 V
Supplier-Device-Package -
Output 0.2 V ~ 4.7 V
Accuracy ±1.5%
Pressure-Type Absolute
Operating-Pressure 2.18 PSI ~ 16.68 PSI (15 kPa ~ 115 kPa)
Port-Size Male - 0.13" (3.17mm) Tube
Port-Style Barbed
Maximum-Pressure 58.02 PSI (400 kPa)
Maximum Operating Temperature + 125 C
Operating temperature range - 40 C
Operating-Supply-Voltage 5 V
Output-Voltage 4.633 V to 4.768 V
Operating-Supply-Current 6 mA
Package-Case SO-8
Port-Type Single Radial Barbed
Mfr Freescale Semiconductor
Package Bulk
Product-Status Active
Applications Board Mount
Operating-Pressure 2．18PSI ~ 16．68PSI (15kPa ~ 115kPa)
Voltage-Supply 4．75V ~ 5．25V
Termination-Style Gull Wing
Maximum-Pressure 58．02PSI (400kPa)
Package-Case 8-SMD Gull Wing Side Port
Supplier-Device-Package 8-SOP
Mfr N✖P USA Inc．
Package Tray
Base-Product-Number MPXAZ6115

Descriptions

PRESSURE SENSOR, 5V, 15/115KPA, SOP 8, PORT
Newark
FREESCALE MPXAZ6115AP / PRESSURE SENSOR ABSOLUTE 8-SOP
ExcessParts.Net
Pressure Sensor 0.2V to 4.7V 15kPa to 115kPa Absolute 8-Pin SOP Tray
Chip One Stop Japan
Pressure Sensor, 5V, 15/115kPa, SOP 8, Port, Reel
Freescale Semiconductor
Pressure Sensor 0.2V to 4.8V 15KPa to 115KPa Absolute 8-Pin SMT Tray
Avnet
Sensors - Pressure SOP SIFEL W/ SIDE PORT
Mouser
PRESSURE SENSOR, 15-115KPA, SOP-8
Farnell
Pressure Sensor 0.2V to 4.8V 15kPa to 115kPa Absolute 8-Pin SMT Tray
Avnet Europe
PRESSURE SENSOR ABSOLUTE 8-SOP
Digi-Key
