HPC46003V20 IC MCU 16BIT ROMLESS 68PLCC National Semiconductor

Half-brick DC-DC Converter

The InQor® Half-brick converter series is composed of next-generation, board-mountable, isolated, fixed switching frequency dc-dc converters that use synchronous rectification to achieve extremely high power conversion efficiency. Each module is supplied completely encased to provide protection from the harsh environments seen in many industrial and transportation applications.



Operational Features

• High efficiencies, up to 91% at full rated load current
• Delivers full power with minimal derating - no heatsink required
• Operating input voltage range: 34 - 135 V
• Fixed frequency switching provides predictable EMI
• No minimum load requirement





Mechanical Features

• Industry standard Half-brick pin-out configuration
• Standard size: 2.390" x 2.490" x 0.512" (60.6 x 63.1 x 13.0 mm)
• Total weight: 5 oz (142 g)





Control Features

• On/Off control referenced to input side
• Remote sense for the output voltage
• Output voltage trim range of -20%, +10%





Safety Features

• 2250 V, 30 MW input-to-output isolation
• UL/cUL 60950-1 recognized (US & Canada), basic insulation rating
• TUV certified to EN60950-1
• Meets directives which facilitates CE Marking in user’s end product
• Board and plastic components meet UL94V-0 standard
• RoHS compliant (see last page)





Protection Features

• Input under-voltage lockout
• Output current limit and short circuit protection
• Active back bias limit
• Thermal shutdown
