HMC1118LP3DE IC RF SWITCH SPDT 13GHZ 16LFCSP Analog Devices Inc.
| Brand Name | Analog Devices Inc. |
|---|---|
| Model Number | HMC1118LP3DE |
| Minimum Order Quantity | 1 |
| Price | Based on current price |
| Packaging Details | anti-static bag & cardboard box |
| Delivery Time | 3-5 work days |
| Payment Terms | T/T |
| Supply Ability | In stock |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Features | - | RF Type | VSAT |
|---|---|---|---|
| Topology | Absorptive | Circuit | SPDT |
| Frequency Range | 9kHz ~ 13GHz | Isolation | 50dB |
| Insertion Loss | 2dB | Test Frequency | 3GHz, 13GHz |
| P1dB | 37dBm | IIP3 | 62dBm |
| Impedance | 50Ohm | Voltage - Supply | 3V ~ 3.6V |
| Operating Temperature | -40°C ~ 85°C | Mounting Type | Surface Mount |
| Package / Case | 16-VFQFN Exposed Pad, CSP | Supplier Device Package | 16-LFCSP (3x3) |
| Highlight | IC RF,RF Integrated Circuit Module,RF IC Chip Module |
||
Product Description
Product Details
General Description
The HMC110 chip is a 5-bit digital attenuator with a 31 dB range in 1 dB steps. Each bit is activated by applying 0V to port A and disabled with -5 V to port A. Port B (as applicable) is biased with the complement of port A. See SMT packaged version HMC110G16 (hermetic).
Features
Bandwidth: DC - 10 GHzLow Insertion Loss: 6.2 dB
31 dB Attenuation Range
Fast Switching: 6 nS
Typical Applications
• Base Station Infrastructure• Portable Wireless
• CATV & DBS
• MMDS & WirelessLAN
• Wireless Local Loop
• UNII & HiperLAN
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Analog Devices |
| Product Category | RF Switches |
| Series | - |
| Packaging | Cut Strip |
| Mounting-Style | SMD/SMT |
| Package-Case | 16-VFQFN Exposed Pad |
| Impedance | 50 Ohm |
| Technology | Silicon |
| Operating-Temperature | -40°C ~ 85°C |
| Features | - |
| Voltage-Supply | 3 V ~ 3.6 V |
| Supplier-Device-Package | 16-LFCSP (3x3) |
| Circuit | SPDT |
| Topology | Absorptive |
| Insertion-Loss | 2 dB |
| P1dB-Compression-Point | 37dBm |
| RF-Type | VSAT |
| Frequency-Lower | 9kHz |
| Frequency-Upper | 13GHz |
| Isolation-Frequency | 50dB @ 3GHz (typ) |
| Insertion-Loss-Frequency | 2dB @ 13GHz |
| IIP3 | 62dBm (typ) |
| Maximum Operating Temperature | + 85 C |
| Operating temperature range | - 40 C |
| Switch-Configuration | SPDT |
| Operating-Supply-Current | 20 uA |
| Operating-Frequency | 9 kHz to 13 GHz |
| Supply-Voltage-Max | 3.6 V |
| Supply-Voltage-Min | 3 V |
| Package-Case | LFCSP-16 |
| Off-Time-Max | 2.7 us |
| Ports of Switches | Dual |
| High-Control-Voltage | 2 V to 3.6 V |
| On-Time-Max | 2.7 us |
Descriptions
RF Switch SPDT 0.009MHz to 13GHz 18dB 16-Pin LFCSP EP T/R
RF Switch ICs Switch SPDT 27dBm Term
